H00609340017 Genuine Air Damper for Haier, Fisher & Paykel Fridges HRF-663CJB HSBS582AS HSBS628AS HSBS610IS RX628DX1 RX611DUX1

Haier and Fisher & Paykel fridges that share cold air between compartments use a damper to regulate it, and H00609340017 is the genuine air damper for a group of them. On file are the Haier HRF-663CJB, HRF-663CJR and HRF-663CJW, the HSBS555, HSBS562IS, HSBS582, HSBS610IS and HSBS628 models, and the Fisher & Paykel RX611DUX1, RX628DW1 and RX628DX1.

Fridge too warm or freezing food? The air damper may be stuck

In fridges where the freezer makes the cold air for both sides, the damper acts as a gate that lets it through to the fresh food section. It opens when the fridge needs cooling and closes once the set temperature is reached. If it sticks shut, the freezer stays cold but the fridge side warms up and food spoils. If it sticks open, items in the fridge can freeze. Ice around the damper, a broken flap or a damper that no longer responds can all cause these symptoms.

Part details

• Genuine part H00609340017
• Air damper that controls cold airflow to the fresh food section
• Listed for Haier HRF-663CJ and HSBS models
• Also listed for Fisher & Paykel RX611DUX1, RX628DW1 and RX628DX1

Fitting the damper

Turn the fridge off at the wall and remove food, shelves and any covers hiding the damper, which usually sits near the top or rear of the fresh food section. Let any ice melt completely. Photograph any wiring plug and how the ducting fits, then swap the damper and reseal the duct joints so air can't bypass it. Allow several hours after switching on for temperatures to settle.

Questions about this part

Could ice be the problem rather than the damper?

Sometimes. If the damper is frozen in place, the root cause may be a defrost fault that needs fixing too. If the damper still doesn't move once it has thawed and power is back on, the damper itself is likely faulty.
