H0020207580 Genuine Outer Door Glass for Fisher & Paykel Front Load Washing Machines WH8560P3 WH1060P3 WH1060P4

Part H0020207580 is the genuine outer glass for the door of Fisher & Paykel front load washing machines. It is listed for the WH8560P3, as well as the WH1060P3 and WH1060P4. The outer glass forms the face of the door you see from the laundry, and you may see it described as the outer rim.

Cracked or damaged Fisher & Paykel washer door glass?

Front loader doors usually combine an outer cover with an inner glass bowl that sits against the door seal. The outer glass takes the knocks from laundry baskets, kids and the odd slammed door, so cracks, chips and deep scratches are common. A cracked outer panel can split further, leave sharp edges or let the door frame flex. Replacing it restores a clean finish and keeps the door safe to handle. If the inner bowl that touches the seal is also cracked, check whether that part needs replacing too.

Part details

• Genuine Fisher & Paykel part H0020207580
• Outer door glass for front load washers
• Listed for WH8560P3, WH1060P3 and WH1060P4

Replacing the outer glass

Unplug the machine before starting. In most front loaders the door is lifted off its hinge and then split into front and rear halves by undoing the screws around the frame. Take photos as you go so the hinge, latch and glass go back in the same order. Fit the new outer glass, reassemble the door and check it latches cleanly before running a rinse cycle.

Questions about this part

Where do I find the model number on my Fisher & Paykel washer?

Open the door and check for the rating label around the door opening, or look on the back of the machine. It shows the model, such as WH1060P3, and a product code. Use both to confirm fit.
