4056009170 Genuine Fan Wiring Adaptor Kit 3 Pin to 4 Pin for Electrolux Appliance Fan Motors, Fan Plug Conversion Kit
- Original part no.
- 4056009170
- Part grade
- Genuine
- Appliance
- Fridge Parts
This part is an order in item. We order it from our supplier once you place your order. It usually takes approximately 5 to 15 days to arrive in store, then we ship it to you or hold it for collection.
Delivery times by state
| WA metro | 1 to 2 business days |
|---|---|
| WA regional | 2 to 5 business days |
| SA and NT | 3 to 6 business days |
| VIC, NSW and ACT | 3 to 6 business days |
| QLD | 4 to 7 business days |
| TAS | 4 to 7 business days |
| Remote areas | 5 to 10 business days |
Estimated times after dispatch. Tracking details are emailed when your order ships.
Local pickup in WAMorley, Myaree or Joondalup
- 3/135 Russell StreetIn stock at this store
Choose Pickup at checkout to collect from our Morley, Myaree or Joondalup store in Western Australia. Please wait for your ready for collection notification before coming in.
Check your model number before ordering. Not sure this part suits your appliance? Send us your model number and we will confirm it for you.
- Genuine manufacturer part
- Tracked delivery Australia-wide
- Parts experts on call
- Secure checkout
Product details
Part 4056009170 is a genuine Electrolux kit for adapting fan wiring from a 3-pin connection to a 4-pin one. Kits like this are needed when the plug on a replacement fan motor doesn't match the original wiring harness, so the new motor can be connected without cutting and joining wires. Confirm the part number against your service information before ordering, as it only suits specific fan and harness combinations.
Why a replacement fan motor may need a wiring adaptor
Manufacturers update fan motors over the life of a model, and a later motor can arrive with a different plug from the one on the original wiring. This adaptor kit bridges that gap, so the 3-pin side and the 4-pin side each connect the way they were designed to. A fan motor usually gets replaced because it has stopped, become noisy or grinding, or slowed right down. Getting every wire to the correct pin matters, because a wrong connection can stop the new fan from running or damage the motor or the control electronics.
Part details
- Genuine Electrolux part number 4056009170
- Fan wiring adaptor kit
- Converts a 3 pin connection to 4 pin
- Avoids cutting and splicing the original harness
| Connection | 3 pin to 4 pin |
|---|
Connecting the adaptor
Unplug the appliance at the wall before reaching the fan wiring. Photograph the existing plug and the wire colours first. Connect the adaptor between the harness and the fan motor exactly as the kit instructions show, and make sure each plug clicks fully home. Tie the wiring clear of the fan blades and any sharp edges, then restore power and check the fan runs.
Questions about this part
When do I need this adaptor kit?
You need it when the fan motor you're fitting has a different connector from the wiring in your appliance, with a 3 pin connection that has to meet a 4 pin one. Compare the plug on your old fan with the new one before ordering.
Specifications
| Original part number | 4056009170 |
|---|---|
| Part grade | Genuine : Genuine part supplied by the appliance manufacturer. |
| SKU | 4056009170 |
| Appliance | Fridge Parts |
| Shipping weight | 0.3 kg |
